Socket – Safety Certified Multi‑Standard Electric Power Outlet Socket

In the world of electrical installations and home improvement, the humble socket is a cornerstone of functionality, safety, and convenience. At Shujie Electric, we understand that a socket is far more than just a point to plug in a device; it is a critical interface between your electrical system and your daily life. Our commitment to engineering excellence drives us to produce sockets that meet the highest standards of performance, durability, and safety. This comprehensive guide delves into the technical specifications, features, and common questions surrounding modern electrical sockets, showcasing why Shujie Electric is the trusted choice for professionals and homeowners alike. Our Socket series includes products such as EU Standard Power Israeli Industrial Socket, Extension Cord Socket, and others.

Understanding Socket Technology: Beyond the Basic Outlet

A socket, or outlet, is a device that allows electrically operated equipment to be connected to the primary alternating current (AC) power supply in a building. Modern sockets incorporate sophisticated design elements to ensure safe and efficient power delivery. Key components include the contact terminals, housing, faceplate, and safety mechanisms such as shutters. Shujie Electric sockets are engineered with precision-grade materials to ensure optimal conductivity, minimal resistance, and long-term reliability, preventing common issues like overheating, arcing, or loose connections.

Detailed Product Parameters of Shujie Electric Sockets

Our sockets are meticulously designed and tested. Below is a detailed breakdown of our standard and advanced model specifications.

Core Technical Specifications (List View)

Rated Voltage: 120V AC / 240V AC (Region-specific models available)

Rated Current: 15A or 20A standard; High-power models up to 32A.

Contact Material: High-conductivity, corrosion-resistant phosphor bronze with silver-plated contacts for superior connection and longevity.

Housing Material: Flame-retardant Polycarbonate (PC) or Thermoplastic, rated for 94V-0, ensuring high impact resistance and safety.

Insulation Resistance: >100 MΩ (as per IEC/EN 60669-1 standards).

Dielectric Strength: Withstands 2000V AC for 1 minute without breakdown.

Mechanical Life: Exceeds 40,000 insertion/extraction cycles.

Safety Shutters: Integrated child-safe protection, requiring simultaneous insertion of both plug pins to access live parts.

Termination Type: Screw terminals (back and side wiring) compatible with solid and stranded copper wire up to 4mm². Quick-connect push-in terminals available on select models.

Certifications: Compliant with and certified by UL/CSA, CE, IEC, RoHS, and relevant national safety standards.
